Industrial cardboard baler HSM V-Press 818 plus 18,5 tons, 185kN, 200kg bales

Industrial cardboard baler HSM V-Press 818 plus 18,5 tons, 185kN, 200kg bales

10,499

  • Industrial Cardboard Baler HSM V-Press 818 plus 185kN, 200kg Bales
  • Pressing power of 18,5 tons or 185 KN
  • Bale weight: up to 200 kg (depending on material)
  • Bale size: L 1200 x W 780 x H max. 700 mm
  • Made in Germany – High-quality product
  • Fast EU Delivery
  • Plug and play – easy to install and simple to use
  • Dimensions:  1709 x 1248 x 2370 mm (Width x Depth x Height:)
  • Machine weight: 1173 kg
  • Filling opening: 1195 x 540 mm (Width x Depth)
  • Motor: 4 kW
  • Voltage / frequency: 3 x 400 V / 50 Hz
  • Volume when pressed: 80 dB
Category:
  • Description

Description

Industrial cardboard baler HSM V-Press 818 plus 18,5 tons, 185kN, 200kg bales

The vertical baling press V-Press 818 plus from HSM® has proven itself in the resource and time-saving disposal of packaging material.

The powerful device achieves a pressing force of 185 kN. It is suitable for compressing punch scraps, mixed paper, clothing, foils, and cardboard. You operate the vertical baling press V-Press 818 plus from HSM® with a membrane keyboard and a text-compatible display. Filling at a comfortable filling height of 958 mm is very easy thanks to the door that can be folded down, including the filling flap. In addition, this door can be opened and closed quickly with a handwheel.

The integrated TorsionControlSystem continuously monitors the correct inclination of the press plate. The bales are strapped with four vertical straps. The maximum weight of the bales is 200 kg, the maximum dimensions are L 1200 x W 780 x H 700 m.



Features of industrial cardboard baler HSM V-Press 818 plus

  • Pressing power of 18,5 tons or 185 KN
  • Bale weight: up to 200 kg (depending on material)
  • Bale size: L 1200 x W 780 x H max. 700 mm
  • Made in Germany – High-quality product
  • Fast EU Delivery
  • Plug and play – easy to install and simple to use
  • Dimensions:  1709 x 1248 x 2370 mm (Width x Depth x Height:)
  • Machine weight: 1173 kg
  • Filling opening: 1195 x 540 mm (Width x Depth)
  • Motor: 4 kW
  • Voltage / frequency: 3 x 400 V / 50 Hz
  • Volume when pressed: 80 dB

Compress in a small space and reduce large amounts of waste: The automatic HSM baling press V-Press 818 combines a powerful motor with compact dimensions – suitable for mobile use. Thanks to the membrane keyboard with a text display, you can operate the system conveniently and easily see the operating status.

  • Compact and robust construction
  • Small footprint
  • Large filling opening
  • Program selection for cardboard and foil
  • Torsion Control System to monitor the inclination of the press plate
  • Foil control keyboard with graphics-capable text display including a status display
  • Available with filling flap (plus model)
  • HSM baling press V-Press 818 – innovative automatic compression

More pressing in less space: The automatic HSM baling press V-Press 818 offers you high motor power on a small footprint.



How does vertical baler HSM V-Press 818 plus work

Cardboard boxes or foils can be conveniently filled into the large system opening. Then start the respective program for pressing and check the inclination of the press plate using the Torsion Control System. The clear film menu display with text field is just as easy to use: This makes it easier for you to handle and provide an overview of the individual functions of the baling press. Sources of error can be identified and rectified quickly and easily.

Reduce your waste volume and prepare waste for further transport or storage: with the automatic HSM baling press V-Press 818 – order now here in our shop.



Industrial cardboard baler HSM V-Press 818 plus specs

Model:HSM V-Press 818 plus
Pressing power:185 kN
Specific pressing power:19,23 N/cm²
Driving power:4 kW
Voltage / Frequency:400 V / 50 Hz
Cycle time when idling:27 s
Volume throughput in idle operation (theor.):5 m³/h
Loading height:958 mm
Loading aperture width x height:1195 x 540 mm
Bale length x Bale width x Bale height:1200 x 780 x 700 mm
Bale weight (up to):200 kg
Width x Depth x Height:1709 x 1248 x 2370 mm
Weight:1173 kg
Type of consumables:Strapping tape
Press material:Punch waste/residue, Cardboard, Mixed paper, Plastic film, Clothing

Industrial cardboard baler HSM V-Press 818 plus video
